Yamaha New high-end hybrid AOI system leads the industrial trend
Yamaha has been at the forefront of the AOI and SMT industries, technology has been leading the industrial trend,YSi-V 12M TypeHS2 Increases Inspection Speed and Precision,and Enhances Capacity and Performance for Specular Components.
Yamaha Motor Europe IM announces that it launched the YSi-V 12M TypeHS2 high-end hybrid automated optical inspection (AOI) system. As the successor to the YSi-V 12M TypeHS, this new very high-speed specification model features increased speed and precision, as well as enhanced specular component inspection capacity/performance.
Development of the YSi-V 12M TypeHS2 aimed for faster processing through improved image processing hardware and image inspection algorithms, and has achieved a more than a 20% increase in three-dimensional inspection speed compared to the existing model. In particular, the new model delivers a significant speed increase of approximately 40% compared to the existing model in printed circuit boards (PCBs) with many component mounting points.
New features include a high-precision mode, enabling capture of clear three-dimensional images. The high-precision 7 μm resolution type includes an all-new-design dedicated three-dimensional image capture projector optical system, significantly improving form reproducibility of extremely small-sized components down to 0201 (0.25 x 0.125mm), and increasing height measurement repeatability.
Furthermore, the optimization of image capture parameters and the employment of newly-developed algorithms has enabled inspection capacity/performance compatible with thin, highly-integrated WLCSP and FOWLP components, whose use on the market has risen dramatically since last year.
The YSi-V 12M TypeHS2 will be showcased at Productronica 2017, an electronics manufacturing and mounting technology exhibition to be held from November 14th to 17th 2017 in Munich, Germany.SMT industry will bring new breakthroughs.
