Yamaha SMT feeder parts and accessories

Time:2012-04-18    Source:www.joy110.com

Yamaha SMT feeder parts and accessories:
We can supply all yamaha feeder smt parts,if there in no matching modles,
Please contact us directly：tony@joysmt.com

SS series smt feeder parts:

Part Name:LEVER,TAPE GUIDE RPART No:KHJ-MC244-00
Part Name:RAIL,UNDERPART No:KHJ-MC104-00
Part Name:TAIL COVER ASSYPART No:KHJ-MC46U-00
Part Name:SS 12MMPART No:KHJ-MC24J-00
Part Name:TAPE GUIDE ASSYPART No:KHJ-MC141-00
Part Name:TAIL COVER ASSYPART No:KHJ-MC16U-00
Part Name:LEVER,TAPE GUIDEPART No:KHJ-MC245-00
Part Name:SS 16MMPART No:KHJ-MC241-00
Part Name:LEVER,TAPE GUIDEPART No:KHJ-MC144-00
Part Name:TAIL COVER ASSYPART No:KHJ-MC26U-00
Part Name:LEVER,TAPE GUIDEPART No:KHJ-MC445-00
Part Name:SS 24MMPART No:KHJ-MC441-00
Part Name:LEVER,TAPE GUIDE FPART No:KHJ-MC145-00

YAMAHA CL8×2mm feeder Parts List
Part No. Part Name
K87-M111H-20X BACK STOPPER
K87-M111B-00X BACK STOPPER AXIS
K87-M117B-00X PLANE WASHER
K87-M11BB-00X SCREW,FLAT HEAD + IB
K87-M112D-10X COIL SPRING
K87-M111G-10X PUSH PIN
K87-M111C-00X PLANE WASHER
K87-M111P-00X SCREW,FLAT HEAD +
K87-M111D-00X PUSH PIN
K87-M112L-10X SPROCKET AXIS ASSY
K87-M111F-10X STOPPER PIN
K87-M1181-00X ROD CONNECT
K87-M1184-00X CONNECT PIN
K87-M111M-00X GASKET
K87-M11B9-00X CIRCLIP E
K87-M111C-00X PLANE WASHER
K87-M11BF-00X SCREW,FLAT HEAD +IB
K87-M111R-00X SCREW,SET
K87-M111X-00X SCREW,SET
K87-M1115-00X CIRCULAR RIVET
K87-M113A-00X CLANK ARM ASSY
K87-M113D-00X ARM
K87-M113E-00X HINGE PIN
K87-M11D7-00X CIRCLIP E
K87-M113L-10X CLAMP LEVER AXI
K87-M113M-00X AXIS PIN
K87-M113H-00X PUSH PIN
K87-M111V-00X SCREW,SET
K87-M111R-00X SCREW,SET
K87-M11BA-00X SCREW,FLAT HEAD
K87-M53BS-00X SCREW,PAN HEAD
K87-M1115-00X CIRCULAR RIVET
KW1-M111A-00X SPRING
KW1-M112A-00X RACKING LEVER ASSY
KW1-M1185-00X MULTI CYLINDER
KW1-M111L-00X BARB CONNECTOR
KW1-M111E-00X SPRING
KW1-M11B1-00X AIR HOSE
KW1-M11B6-00X BOLT,HEX SOCKET HEAD
KW1-M114A-00X HAND LEVER ASSY
KW1-M116K-00X LEVER AXI
KW1-M1177-00X MAIN ARM
KW1-M114N-00X GUIDE AXIS
KW1-M1320-00X SPROCKET ASSY
KW1-M1340-00X TAPE GUIDE ASSY
KW1-M134T-00X LEAF SPRING
KW1-M1110-010X BODY ASSY
KW1-M1112-00X KNOCK PIN
KW1-M1113-00X KNOCK PIN
KW1-M1150-00X HANDLE LEVER ASSY
KW1-M116F-00X LEVER AXIS PIN
KW1-M115D-00X GUIDE PIN ASSY
KW1-M116D-00X TENSION LEVER ASSY
KW1-M116F-00X LEVER AXIS PIN
KW1-M114L-00X COVER
KW1-M111T-00X SCREW,THIN HEAD
KW1-M116J-00X METAL SHAFT
KW1-M1131-00X CLAMP LEVER UNIT
KW1-M1132-00X CLAMP LEVER ASSY
KW1-M1191-00X DRIVE ROLLER UNIT
KW1-M1192-00X INDENTATION LVR ASSY
KW1-M119F-00X DRIVE ROLLER ASSY
KW1-M119K-00X SPRING
KW1-M119L-00X IDLE ROLLER ASSY
