Yamaha feeder calibration jig

Location  : Home > Products> SMT Feeder Calibration jig> Yamaha feeder calibration jig

YAMAHA FEEDER CALIBRATION JIG

Part No.: YAMAHA FEEDER CALIBRATION JIG

Brand: YAMAHA

Name/Size: FEEDER CALIBRATION JIG

Specifiction: YAMAHA FEEDER CALIBRATION JIG

Immediate inquiry
< >
Product description YAMAHA FEEDER CALIBRATION JIG
1, Simple structure, easy operation, function optimization. And the use of high-precision 0 gap guide, to ensure positional stability, greatly improve work efficiency
2, Accurate detection. Reclaimer position, height, strut height can be done accurately measured. To better grasp the quality status;
3, The use of 10 'color LED display , LED lighting ring, 50 times magnification CCD camera, making more compact structure, beautiful. Effectively reducing eye fatigue, improve the quality of work;
4, Easy to operate, and can simulate the placement machine, automatic continuous observation reclaimer position, a clearer grasp FEEDER continuous operation quality, and thus more effective control of polishing material ratio;
5, You can choose a variety of models such as FUJI CP6, YAMAHA, SANYO; PANASONIC, UNIVERSAL, SONY; JUKI; SAMSUNG;

6, The functions and features:
1.     Precise XY axis adjustment;
2.     axis camera can be directly adjusted;
3.     220V/24V DC power supply;
4.     black and white cross reference cursor;
5.     Automatically step function;
6.     bright LED display;
7.     precise control fixtures feeders;

8.     precise 8mm,12mm,16mm and 24 mm feeders control band.



Uses for : FEEDER calibration jig for calibration of various models

Power supply: 220V/24V

Compressed air requirements: 5kg/cm²

Dimensions: L500mm * W 350mm * H550mm

Weight: about 35kg
