The technical indicators of PCB placement machine
PCB placement machine is used to achieve high-speed, high-precision fully automatic placement of components of the device, The entire SMT, the production of the most critical and most complex equipment. Mounter is the main equipment in the SMT production line. Now, the placement machine has developed from the early low-speed mechanical placement machine for high-speed optical centering machine, and to the multi-functional, flexible connection modular development. Is a new generation of electronic assembly technology, it will be the traditional electronic components compressed into a volume of only a few tenths of the device, thus achieving the electronic product assembly of high density, high reliability, miniaturization, low cost, and production automation. It is the introduction of a large number of reflow, Matsushita Mounter, for the industry to provide users with a large number of products and services, many well-known professional manufacturers have close cooperation relationship.

PCB placement machine main parameter:
1. the type of components can be mounted, specifications, patch orientation, substrate size, patch range compliance with the specification indicators.

2.The patch speed: 1608 chip components to test CPH placement rate is not less than the nominal IPC9850 speed of 60%, or SPC speed is not greater than the nominal speed of 2 times.

3, The fly rate is not greater than 3 ‰.

Mounter Operating System:
1. a variety of indicators, buttons, the operating handle looks complete, operation, display normal;
2. the computer system is working properly;
3. input and output system is working properly.

The versatility of the placement machine can be mounted from 0603 components (0.6 × 0.3 mm chip components) to 33.5 mm square large parts. Substrate transfer mode can be transmitted from the line or return to any choice, that is, to facilitate the production of units such as simple production and free to arrange the production line, improve the versatility of the equipment. High quality As the laser sensor monitors the component to the moment of placement, it is possible to prevent the falling element, bringing back the components and standing the components. Chassis with integrated casting, with good vibration characteristics and durability, in order to achieve a high quality of the placement, to meet the long-term use.
